Permanent Closed-Loop Operation as a Measure for Improving Power Supply Reliability in a Rural Medium Voltage Distribution Network   G. Štumbrger, M. Rošer, M. Pintarič and B. Polajžer   2023/07/20

Abstract

Power supply reliability is one of the critical elements of power quality. Its improvement in medium voltage distribution systems in urban areas is typically achieved by cabling. Unfortunately, this approach is often too expensive to be applied in rural areas. One of the possible alternative solutions that can be used in rural medium voltage distribution networks is permanent closed-loop operation. It requires the introduction of additional reclosers with properly parametrized protection relays enabling directional protection. This paper focuses on the case study performed in the 20 kV rural distribution network of Elektro Celje d.d.. Two feeders, where the reliability of the power supply was low, were analyzed. Results of techno economical evaluation eliminated cabling as a viable solution. The permanent closed-loop operation was selected and implemented after proper placement and parameterization of relays with directional protection functions. The results of two years operation in permanent closed-loop arrangement of feeders show substantial improvement in the reliability of power supply.

Authors and affiliations

G. Štumbrger(1), M. Rošer(2), M. Pintarič and B. Polajžer(1)
(1) Faculty of Electrical Engineering and Computer Science University of Maribor Koroška cesta 46, 2000 Maribor (Slovenia)
(2) Elektro Celja d.d. Vrunčeva 3 a, 3000 Celje (Slovania)

Key words

Rural medium voltage distribution network, permanent closed-loop operation, power supply reliability.

References

[1] W. T. Huang, T. H. Chen, G. C. Pu, Y. F. Hsu, T. Y. Guo, Assessment of Upgrading Existing Primary Feeders from Radial to Normally Closed Loop Arrangement, IEEE Transmission and Distribution Conference and Exhibition, 3, 2002.

[2] Y. Guo, Feasibility Study of Upgrading Primary Feeders from Radial and Open-Loop to Normally Closed-Loop Arrangement, IEEE Transactions on Power Systems (2004), vol. 19, no. 3, pp. 1308 –1316.

[3] W. T. Huang, S. T. Chen, Line Loss Reduction by Distribution System Upgrading from Radial to Normally Closed- Loop Arrangement, Ninth International Conference on Hybrid Intelligent Systems, Washington, USA, vol. 3, pp. 334 – 339, 2009.

[4] K. Deželak, M. Rošer, R. Škof, T. Kastelic, and G. Štumberger, The impact of feeders in closed-loop arrangement on harmonic distortion and power losses, International Conference on Renewable Energies and Power Quality (ICREPQ’13), Bilbao (Spain), March 2013.

[5] N. Okada, H. Kobayashi, K. Takigawa, M. Ichikawa, K. Kurokawa, Loop power flow control and voltage characteristics of distribution system for distributed generation including PV system, 3rd World Conference on Photovoltoic Energy Conversion, May 11-18, Osaka. Japan, pp. 2284-2287, 2003.

[6] G. Štumberger, K. Deželak, M. Rošer, R. Škof, and T. Kastelic, Medium-voltage distribution feeders in open-loop and closed-loop arrangement, International Conference on Renewable Energies and Power Quality (ICREPQ’12), Santiago de Compostela (Spain), March 2012.

[7] M. Ojaghi and R. Ghahremani, Piece-wise linear characteristic for coordinating numerical overcurrent relays, IEEE Trans. Power Del. (2017), vol. 32, no. 1, pp. 145-151.

[8] Measuring Relays and Protection Equipment- Part 151: Functional Requirements of Over/Under Current Protection, Standard IEC 60255-151, 2009.

[9] Inverse-Time Characteristics Equations for Overcurrent Relays, IEEE, Standard C37.112-2018, 2018.

[10] K. V. Price, R. M. Storn in J. A. Lampinen, Differencial Evolution, Springer, 2005.

[11] B. Polajžer, M. Pintarič, M. Rošer, and G. Štumberger, Protection of MV Closed-Loop Distribution Networks with Bi Directional Overcurrent Relays and GOOSE Communications, IEEE Access (2019), vol. 7, pp. 165884 – 165896.
